DZL
Do you have a DZL|plate in use or are you interested in a DZL?
Then you are at the right place. This page will provide you with all the important information:
- What exactly is the DZL|plate?
- How does the production of a DZL|plate work?
- What are the specific advantages of the DZL?
- How long is the service life of the DZL?
- What supplementary products we recommend!
For questions or orders, please click here.
DZL|plate & DZL|plateXL
Reduce your make-ready times - with the DZL|plate from Marbach.
Also available as DZL|plateXL for large-format corrugated board machines with two-part protection plate.
Digital zone levelling
Normally, during packaging production, zone levelling is done for each individual order. This costs time and therefore money.
Our digital zone levelling (DZL) can completely replace this order-related process. And thus makes order-related height compensation permanently unnecessary.
For you, this means significantly reduced make-ready times for each individual job. Thanks to its innovative coating, the DZL|plate is now even more durable!
AND HOW EXACTLY DOES THE PRODUCTION OF A DZL WORK?
1. CUSTOMER:
Unevenness in the cutting platen of the machine is measured using a grid cutting-die and pressure-sensitive foil.
=> Impression.
2. MARBACH:
- Data is evaluated, height level for compensation is determined.
- Height level is applied to the protection plate.
- DZL|plate is delivered to the customer.
3. CUSTOMER:
DZL|plate is inserted into the die-cutting machine and ensures permanently reduced make-ready times.
- Time saving.
- More productivity.
YOUR ADVANTAGES WHEN USING A DZL.
1. Machine-related tolerances are compensated (plane parallelism, uniform height during die-cutting).
=> Shorter make-ready times.
2. The DZL permanently replaces the normally necessary order-related zone levelling.
=> Time saving. => Cost saving. => Higher productivity.
3. Less die-cutting force is required with the DZL.
=> The DZL protects the machine.
4. Optimum conditions in the platen during die-cutting: cutting rules are used very evenly.
=> Increased tool service life.
5. Height level is available digitally.
=> Fast and uncomplicated reordering.
6. A DZL pays for itself in no time at all. You can find more information here.
7. Disadvantages of conventional zone levelling with tissue paper are equalized:
=> No problems with gluing, no tissue paper that disintegrates, and no unnecessary machine downtimes.
WHAT IS THE SERVICE LIFE OF THE DZL?
Of course, the service life of a DZL depends very much on how it is used.
Under normal conditions, the service life is:
- DZL|plate (paperboard) > 1 year
- DZL|plateXL (corrugated board) > 6 months
Lukas Holler
Contact person
tel. +49 7131-918-0
Please note of our supplementary products we recommend!
Special protection plate cleaner.
The DZL should be cleaned daily to ensure optimum functionality. Please be sure to use the Marbach special cleaner marbacleaner for this purpose. Its composition is perfectly matched to the DZL material and thus ensures optimum cleaning and a long service life for your DZL.
Available from us under item no.: 07223.
Platen cleaning device.
To maximize the benefits of using a DZL|plate, the machine should be thoroughly cleaned with a platen cleaning device before taking a digital impression. We also recommend cleaning the platen from time to time.
Our tip: The mplaten|cleaner-smart (art. no.: G-2255).
This allows the platen to be cleaned quickly and efficiently by the machine operator. The perfect addition to the DZL|plate and DZL|plateXL.
Would you like to find out more about the mplaten|cleaner? Click here for more information:
Universal oil spray.
The care of the cutting platen supports the optimal function of the DZL. We recommend using a universal oil spray such as Ballistol. This food-grade oil has H1 approval and is colorless, scentless, and tasteless. It offers high-quality rust protection for all types of machines and appliances and supports the long service life of your DZL.
Available from us under item no.: 910172.
